О нас Zhenjiang Yanyang Engineering Co., Ltd.
Over the past three decades, we have successfully delivered a wide range of large-scale marine engineering vessels to clients across Asia, South America, Europe, and Africa. Meanwhile, we have also been deeply involved in numerous port construction and dredging projects.
As the global landscape evolves, we remain committed to serving international clients with expertise, technical excellence, and a dedicated team.
Наша продукция
Pile Driving Barge (Piling Barge)
Model: 110m pile leader height Pile Driving Barge
Params: LENGTH OVERALL : ～118.50 m2
BREADTH : 37.70 m4
DEPTH : 7.70 m5
PILE FRAME HEIGHT (AB. DESIGN DRAFT) : 137.00 m10
TYPICAL DIAMETER OF PLANTING PILE : Ø4000 mm
TYPICAL LENGTH OF PLANTING PILE : 107 m + DEPTH OF WATER
TYPICAL WEIGHT OF PLANTING PILE : 400 t
Split Hopper Barge
Model: 2600m³ Split Hopper Barge (CCS)
Params: Overall Length : 76.95 m
Waterline Length : 75.92 m
Molded Breadth : 15.60 m
Molded Depth : 6.00 m
Design Draft : 4.00 m
Beam : 9.15 m
Frame Spacing : 0.60 m
Main Engine Power : 3740 kW × 2
Crew : 10 persons
Ice Class : Ice Class B
Backhoe Dredger
Model: EX5500
Params: Overall Length (m) : 71.5
Beam (m) : 22
Draft (m) : 2.5
Excavator Model : Hitachi EX 5500
Excavator Power (kW) : 2 × 1076
Dredging Depth (m) : 18 / 24 / 32
Capacity (m³) : 15 / 18 / 20.5
Propulsion Power (kW) : 2 × 350
Grab Dredger
Model: Self propelled grab dredger
Params: 25m³ Grab Dredger
I. Main Technical Parameters:
Year of Completion: 2012
Overall Length: 58.00 m
Length Waterline: 58.00 m
Length Between Perpendiculars: 56.30 m
Molded Breadth: 22.60 m
Molded Depth: 4.80 m
Designed Draft: 3.00 m
Deck Camber: 0.30 m
Navigation Area: Coastal
Crew: 10 persons
Frame Spacing: 0.60 m
Grab Capacity: 25 m³
Designed Displacement: 3651.308 t
Generators: SB-HW4 × 2
Gross Tonnage: 2349 T
Net Tonnage: 705 T
Main Engine Model: Weichai X6170ZC-21
Quantity: 2 units
Rated Power: 456 KW
Rated Speed: 1500 r/min
Reduction Gear Box Model: HCD400A
Reduction Ratio: 5:1
Trailing Suction Hopper Dredger
Model: TSHD
Params: Main Particulars
Length over allapprox. 171.20 m
Length between perpendiculars : 160.00 m
Breadth, moulded : 36.00 m
Depth, moulded : 15.80 m
Draft at International Freeboard : 9.50 m
Max. Hopper Capacity approx. 26800 m³
Suction Pipe Diameter : Φ1200 mm
Dredging Depth : 40/70/115 m
Speed at draft 11.5 m～15.5 kn
Total installed power : 27726 kW
Main diesel engines : Wartsila 3*8000 kW
Auxiliary/harbor generator : Wartsila 2*1600 kW
Emergency generator : Cummins 1* 526 kW
Main thruster : Wartsila 2*10500 kW
Inboard Dredge Pump : HK 2*6000 kW
Under water pump : HK+BKKER 2*3300 kW
Jet water Pumps : CCCC 2*2000 kW
Bow thrusters : ZF 2*1100 kW
Stern thruster : ZF 1*1100 kW
Class:
CCS, CSA Trailing Suction Dredger, Dredging within R1, DP-1
AUT-0: G-P01L1,S,C,RC,NEC2,INC,RSC1,AFS); G-ECO(BWM(T))
Cutter Suction Dredger
Model: 1000-8000m³/h CSD
Params: Super size 8000m³/h self-propelled cutter suction dredger for major port construction ,reclamation, deep-sea channel excavation. 30m dredging depth, 8000m discharge distance.
